NKE-225x-9 25kW/9ft

This very light weight antenna, perfect for all high seas, offshore, inland and fishing vessels operates at an ideal power rate, and with very stable results. Technical Specifications of the antenna: - Output Power: 25kW - Transmitting Frequency: X-band (9410±30MHz) - 7ft scanner (open array) - Beam width: Horizontal 0,8°, Vertical 20° - Rotation speed: 16, 20, 24 rpm - Pulse width/freq. repetition: 0.07μs/2250Hz,0.2μs/2250Hz, 0.3μs/1900Hz,0.4μs/1400Hz, 0.8μs/750Hz,1.0μs/650Hz, 1.2μs/510Hz - Max. Range: 96NM - Range scales: 0.125, 0.25, 0.5, 0.75, 1.5, 3, 6, 12, 24, 48, 72, 96 NM

2020-04-22T16:56:46-03:0022/04/2020|
Read More

JMA-5300Mk2

The new JMA-5300 PROLINE integrates the latest leading technologies with a set of advanced features that allow running radar images faster and efficiently. Also the brushless antenna motors in the scanner guarantee for extended lifetime. Constaview™ is realized through the use of high-speed processors. The radar image is fully processed within a few milliseconds before displayed, generating a smooth image rotation when sailing in Head-Up mode. When changing to North-Up, the new radar image is displayed without any delay caused by the scanner rotation. Other ship’s movement and speed can be monitored from length and direction of their trails, primary serving for collision avoidance. The JMA-5300 PROLINE integrates four different trail length modes that will show a ship’s course instantly, a unique operational feature that allows for more flexibility.

2020-06-09T12:37:19-03:0022/04/2020|
Read More

JMA-5200Mk2

The new JMA-5200 PROLINE continues the success of its predecessor, reaching a high level of performance, designed to seamlessly run radar images faster and more efficiently than ever before. Also the brushless antenna motors in the scanner guarantee for extended lifetime. Constaview™ is realized through the use of high-speed processors. The radar image is fully processed within a few milliseconds before displayed, generating a smooth image rotation when sailing in Head-Up mode. When changing to North-Up, the new radar image is displayed without any delay caused by the scanner rotation. Other ship’s movement and speed can be monitored from length and direction of their trails, primary serving for collision avoidance. The JMA-5200 PROLINE integrates four different trail length modes that will show a ship’s course instantly, a unique operational feature that allows for more flexibility.

2020-06-09T12:32:26-03:0022/04/2020|
Read More

JMA-3300

The JMA-3300 series is JRC's newest radar, featuring a 10.4-inch ultra bright LCD, and incorporates the latest digital signal processing for excellent target identification and detection in a compact design. Smooth and comfortable operation is guaranteed with the solid and responsive feel of the keys. A dedicated jog-dial is conveniently integrated as well as the function keys for one-touch access to GAIN, SEA and RAIN. The JMA-3300 also incorporates 4 soft-key switches just below the display that can be assigned by the user. Here you can specify commonly used functions, making it even simpler to navigate. Based on JRC's patented technology found in the bigger radars, the new JMA-3300 integrates Semi-Constaview™. This allows fast processing of targets, showing true trails in Head-Up mode, without interference of fixed targets, such as land or mass. Besides the display and operating keys, this compact all-in-one unit has the processor integrated, allowing for a flexible installation approach.

2020-06-15T00:30:46-03:0022/04/2020|
Read More

JMA-3400

The newest addition to the JRC radar portfolio is the JMA-3400. This lightweight radar has user-friendly operation system and is specially designed for fishing boats, non-international trading vessels and workboats. The sectors that will definitely gain with this product, are offshore, inland and fishing. The system can be completed by choosing from a variety of 2 ft, 3,9 ft, 4 ft and 6 ft scanners.

2020-06-15T00:32:22-03:0022/04/2020|
Read More

JMA-1030

The new JMA-1030 radar series is JRC’s very first touch operated radar with new dome scanners that provide you with highly accurate target clarity and ease of mind of your surroundings during night or intense fog. The high definition 7-inch wide display has allowed JRC engineers to develop an exciting new software approach that offers an incredibly easy-to-use icon based navigation experience with simple menus and dedicated functions. The set of icons has been carefully designed. We brought the elements and visual style of our commercial class Multi Function Display (MFD) to our most compact series of radars. Built with the proven quality you expect from us. JRC engineers custom designed the System-on-Chip (SoC) inside the new JMA-1030 series to be an extremely powerful tool and at the same time makes the display compact and very power efficient. The new radar has the ability to display 50 AIS1 symbols, and 10 MARPA™2 tracking targets as standard.

2020-06-15T00:44:03-03:0022/04/2020|
Read More

JMA-610

The JMA-610 has many of the characteristics of the JMA-609. After all, why mess with a good thing! Still, the technicians of Alphatron and JRC have succeeded in adding functions that are actually useful. The photoshot® and AIS functionalities, in particular, are two exceptional additions to this radar, a navigation centre that is considered the best of its kind. But operator feedback has also inspired changes that have further improved image quality and ease of use. The JMA 610 is able to convert the radar screen into a multifunctional display system without limitations. However for the operator who is only interested in using the basic radar functions the extra functions can be switched on and off. The new JMA 610 is designed to seamlessly fit into the Multifunctionline concept in case a combination with other MF instruments within the Multifunctionline is realized. All necessary control buttons for the radar within a hand’s reach due to the handy design. A build in roller ball is available to operate the various menu functions.

2020-06-09T11:56:57-03:0022/04/2020|
Read More

NKE-1066 4kW/1.5ft

This very light weight antenna, perfect for small offshore, inland and fishing vessels operates at a low power rate, but with very stable results. Technical Specifications of the antenna: - Output Power: 4kW - 1.5ft scanner (450mm radome) - Beam width: Horizontal 5.2°, Vertical 25° - Rotation speed: 16, 20, 24, 27, 30, 36, 42, 48 rpm - Pulse width/freq. repetition: 0.08μs/4000Hz, 0.08μs/2250Hz, 0.13μs/1700Hz, 0.25μs/1700Hz, 0.5μs/1200Hz, 0.8μs/750Hz - Adding range scale: 1, 2, 4, 8, 16, and 32＊1 NM

2020-04-22T16:56:46-03:0022/04/2020|
Read More

NKE-2043 4kW/2ft

This very light weight antenna, perfect for small offshore, inland and fishing vessels operates at a low power rate, but with very stable results. Technical Specifications of the antenna: - Output Power: 4kW - Transmitting Frequency: X-band (9410±30MHz) - 2ft scanner (620mm radome) - Beam width: Horizontal 4°, Vertical 25° - Rotation speed: 16, 20, 24, 27, 30, 36, 42, 48 rpm - Pulse width/freq. repetition: 0.08μs/4000Hz, 0.08μs/2250Hz, 0.13μs/1700Hz, 0.25μs/1700Hz, 0.5μs/1200Hz, 0.8μs/750Hz, 1.0μs/650Hz - Max. Range: 48NM - Range scales: 0.125, 0.25, 0.5, 0.75, 1.5, 3, 6, 12, 24, 48 NM - Adding range scale: 1, 2, 4, 8, 16, and 32＊1 NM

2020-04-22T16:56:46-03:0022/04/2020|
Read More

NKE-2044 4kW/2ft

This very light weight antenna, perfect for small offshore, inland and fishing vessels operates at a low power rate, but with very stable results. Technical Specifications of the antenna: - Output Power: 4kW - Transmitting Frequency: X-band (9410±30MHz) - 2ft scanner (620mm radome) - Beam width: Horizontal 4°, Vertical 25° - Rotation speed: 16, 20, 24, 27, 30, 36, 42, 48 rpm - Pulse width/freq. repetition: 0.08μs/4000Hz, 0.08μs/2250Hz, 0.13μs/1700Hz, 0.25μs/1700Hz, 0.5μs/1200Hz, 0.8μs/750Hz, 1.0μs/650Hz - Max. Range: 48NM - Range scales: 0.125, 0.25, 0.5, 0.75, 1.5, 3, 6, 12, 24, 48 NM
